JRF-B series high temperature coal-fired hot stove |
|
Overview: JRF-B series high temperature coal-fired hot stove all mechanical chain-grate coal-fired installations. High-temperature heat exchanger can be installed plate, pipe, such as heat pipe heat exchanger, a high temperature output, calorific value, high thermal efficiency advantages of 100-450 can be prepared? C clean hot air. Equipment technical indicators have reached advanced domestic level. Widely used in chemical, food, minerals, food, building materials and other industries. Can be used for heating, drying, baking, the ideal heat source heat setting, with a variety of drying devices.
Applications: ◆ chemical industry: dry chemical products ◆ food industry: Food dewatering and drying ◆ food industry: Food Baking ◆ the construction industry: Asphalt dissolved, concrete cylinder of heat ◆ timber industry: man-made fibre board, particle board, wood drying ◆ air-conditioning industry: Heating heat ◆ growing industry: vegetable greenhouse heating ◆ textile industry: heat setting machine, resin finishing machine dry.

技術參數:
|
型號 |
輸出熱量 |
輸出風量 |
輸出溫度 |
耗煤量 |
煙氣引風機型號 |
GMF100 |
100 |
由輸出溫度定 |
100-450 |
260-280 |
Y5-47NO5 7.5KW |
GMF120 |
120 |
100-450 |
390-420 |
Y5-47NO5 7.5KW |
GMF180 |
180 |
100-450 |
520-560 |
Y5-47NO6 15KW |
GMF240 |
240 |
100-450 |
560-700 |
Y5-47NO6 18.5KW |
GMF300 |
300 |
100-450 |
780-800 |
Y5-47NO8 22KW |
GMF360 |
360 |
100-450 |
910-980 |
Y5-47NO8 30KWKW |
GMF420 |
420 |
100-450 |
1040-1120 |
Y5-47NO8 30KW |
GMF480 |
480 |
100-450 |
1300-1400 |
Y5-47NO9 45KW |
GMF600 |
600 |
100-450 |
1560-1680 |
Y5-47NO10 55KW |
GMF720 |
720 |
100-450 |
1750-2000 |
Y5-47NO10 55KW |
GMF780 |
780 |
100-450 |
1890-2180 |
Y5-47NO10 75KW |
GMF960 |
960 |
100-450 |
2320-2700 |
Y5-47NO12 75KW |
|
|
|
|
|
 |
