Features:
Can be set appropriate operating conditions, in accordance with ventilation drying corresponding state can be arbitrary regulation of temperature, air flow and other operating conditions.
Adjust freely processed water, as can freely adjust the drying plant material flow stops, residence time. So can arbitrarily set the water content of processed products.
Little damage shape, in the Division of drying device, which is stationary mobile, and can be almost does not destroy the shape of products, even a small amount of dust flying, can be set up through the pipeline weak wind or bag filter collection.
Various conveyors can be used, according to the different drying materials, in addition to all kinds of metal mesh belt, the vibration plate can also be used.
Conveyor can be cleaning, heating and drying room separate room, with easy cleaning transmission network.
Upon request, in the assembly floor cleaning equipment installation will be on the floor in a small swap materials from scratch expected to end.
According to different water production materials, the series can choose to use multiple devices to increase production.
Technical parameters:
| 項目\型號 |
DWD1.2×8 |
DWD1.2×10 |
DWD1.6×8 |
DWD1.6×10 |
DWD2×8 |
DWD2×10 |
| 干燥面積 m2 |
9.6 |
12 |
12.8 |
16 |
16 |
20 |
干燥段長×帶寬 m
length×belt width |
1.2×8 |
1.2×10 |
1.6×8 |
1.6×10 |
2×8 |
2×10 |
| 單元數 |
4 |
5 |
4 |
5 |
4 |
5 |
| 使用溫度 ℃ |
50-150 |
| 蒸汽工作壓力 Mpa |
0.2-0.6 |
| 蒸汽耗量 Kg/h |
120-250 |
150-375 |
150-375 |
170-470 |
225-600 |
450-1200 |
| 干燥時間 h |
0.2-1.5 |
0.25-1.5 |
0.2-1.5 |
0.25-1.5 |
0.2-1.5 |
0.25-1.5 |
| 蒸發能力 Kg/H2O |
60-160 |
80-220 |
75-220 |
95-250 |
100-260 |
120-300 |
| 裝機容量 kW |
11.4 |
13.6 |
11.4 |
13.6 |
19.7 |
11.77 |
| 外形尺寸 dim.(LxNxH) m |
9.77
×1.5
×2.83 |
11.77
×1.5
×2.83 |
9.77
×2.44
×2.83 |
11.77
×2.24
×2.83 |
9.77
×2.66
×3.50 |
11.77
×2.66
×3.50 |
| 重量 kg |
4800 |
5780 |
5400 |
6550 |
6350 |
7800 |
注:用戶在選型時,應根據產量、物料含水量等參數選擇2臺或多臺串聯方式進行增加干燥面積,以滿足使用要求,提高產品的產量和質量。
Technical parameters:
| 物料名稱 |
顏料 |
鐵酸鹽 |
氧化鐵 |
抗生物質 |
調料 |
飼料 |
| 干燥面積 m2 |
32 |
16 |
19 |
19.2 |
19.2 |
32 |
| 物料處理量 Kg/h |
312 |
533 |
533 |
1200 |
1200 |
1200 |
| 物料水份 % |
65 |
60 |
80 |
35 |
35 |
60 |
| 成品水份 % |
2 |
0.1 |
1.0 |
10 |
10 |
2 |
| 熱源 |
蒸汽 0.5Mpa |
蒸汽 0.5Mpa |
蒸汽 0.4Mpa |
蒸汽 0.7Mpa |
蒸汽 0.6Mpa |
蒸汽 0.6Mpa |
| 熱源消耗量 Kg/h |
500 |
600 |
800 |
950 |
|
|
| 前處理機 |
|
|
|
|
700 |
900 |
| 材料形狀 |
|
|
|
|
粉狀 |
粒狀 |
